To mount Arlo Essential XL on vinyl siding without leaks, skip drilling through the siding itself — use a no-hole vinyl siding hook (Hillman, OOK, or Hyde) that grips the bottom lip of a course, or attach a PVC mounting block and screw the Arlo bracket into that. If you must drill, seal the screw hole with butyl tape and a dab of polyurethane sealant before driving stainless screws into the sheathing through a backer. Either method keeps water out of your wall while giving the Arlo Essential XL a rock-solid base. Below is the full method, the materials list, and a few alternative wireless cameras worth bookmarking for the rest of the house.
Why you can't just drill straight into vinyl
Top Picks
Vinyl siding is a rain-screen system. It hangs loose from nails so it can expand and contract with temperature, and it relies on a house wrap (Tyvek or similar) behind it to shed any wind-driven water that gets past the panels. The moment you drive a screw through the face of vinyl siding, you create three problems: the siding itself can crack in cold weather as it tries to move around the fastener, the screw hole becomes a direct path for water into the wall cavity, and over-tightening warps the panel into a permanent wave. None of this is theoretical — it's the most common cause of hidden rot on homes with mounted cameras, satellite dishes, and house numbers.
The good news: the Arlo Essential XL weighs under a pound and a half. It does not need lag bolts into a stud. A 4-inch PVC mounting block, or even a properly installed siding hook, easily holds it for years.
Tools and materials you'll need
- Vinyl siding mounting block (4" x 6" PVC, paintable) — or no-hole vinyl siding hook
- Zip tool (siding unhooking tool, $8 at any hardware store)
- Butyl tape (1/8" thick, sometimes sold as "window flashing tape")
- Polyurethane sealant (NP1, Vulkem 116, or Loctite PL Premium — not silicone, which won't bond to Tyvek)
- Four #8 x 1-1/2" stainless steel exterior screws
- 3/16" drill bit and cordless drill
- Small torpedo level
- The Arlo Essential XL outdoor magnetic mount that ships in the box
Step-by-step: how to mount Arlo Essential XL on vinyl siding
Option A — No-drill: vinyl siding hook method
This is the easiest path if your camera sits between two horizontal siding courses. Use a vinyl siding hook (Hillman, OOK, or Hyde — all under $5). It's a small stainless tab that slides up under the lip of a siding panel and locks into place by gravity. Unhook the panel above with your zip tool, slide the hook in, re-lock the panel, and you're done — zero holes. The Arlo Essential XL's magnetic mount has a screw-flange base; you screw it to a small piece of cedar or PVC scrap, then hang that scrap on the hook. It sounds janky in writing, but on the wall it's invisible behind the camera and supports 10+ pounds.
Option B — Mounting block method (more secure, slightly more work)
A PVC mounting block sits flush against the siding and gives you a flat, paintable surface to screw the Arlo bracket into. Here's the sequence:
- Mark your location. Hold the Arlo Essential XL where you want it and use the included paper template (or just the bracket) to mark the four screw points with a pencil.
- Unhook the siding course above. Slide the zip tool up and along the bottom edge of the course above your mark, then pull down and out to unlock about 18 inches of seam.
- Trace and cut the block. Hold the mounting block over your marks and trace its outline onto the siding. Cut along the line with a sharp utility knife — vinyl scores and snaps cleanly.
- Apply butyl tape. Run a strip of butyl tape around the back perimeter of the mounting block. This is the actual waterproofing layer.
- Pre-drill into the sheathing. Drill four 3/16" pilot holes through the exposed Tyvek and into the OSB sheathing behind. Dab polyurethane sealant into each hole.
- Mount the block. Screw the block to the sheathing with #8 stainless screws. Don't over-tighten; the butyl tape compresses against the Tyvek and creates the seal.
- Re-lock the siding above. Push the unhooked course back down until it clicks over the course below.
- Attach the Arlo bracket. Now screw the Arlo Essential XL's mount directly into the PVC block. Clip the camera on, aim it, done.
Routing the (optional) power cable
If you're running the Arlo Essential XL on solar or battery only, skip this. If you bought the wired version or want a permanent USB feed, drill a 1/2" hole through the mounting block (not the siding) and through the sheathing behind it. Run the cable, then pack the hole with sealant from both sides. The mounting block hides the entry point and keeps water from ever touching the siding penetration.
Alternative wireless outdoor cameras that mount the same way
If you're building out a multi-camera system, or you want a second brand for redundancy, every camera below uses a similar small-footprint bracket that works perfectly with the PVC mounting block method above. The leak-proof installation is identical — only the camera changes.
| Camera | Resolution | Battery life | Subscription required? | Best for |
|---|---|---|---|---|
| Blink Outdoor 4 XR (4-cam) | 1080p | 2 years | No (local USB storage) | Whole-home coverage |
| Blink Outdoor 4 (single) | 1080p | 2 years | No (local USB storage) | Single entry point |
| aosu T2 Pro Dual Cam | 3K dual lens | 180 days | No (microSD) | Driveway + porch in one unit |
| Blink Outdoor 2K+ | 2K | 2 years | No (local USB storage) | Sharper image than Outdoor 4 |
| Blink Outdoor 4 System | 1080p | 2 years | No (local USB storage) | Sync Module 2 starter kit |
Blink Outdoor 4 XR Wireless Camera (4-cam kit)
If the Arlo Essential XL is going on the front of the house, a four-pack of Blink Outdoor 4 XR cameras is the cleanest way to cover the rest. They mount with a tiny ball-joint bracket — two screws into your PVC block and the camera snaps on. The two-year battery life means you're not climbing a ladder twice a year, and the Sync Module 2 lets you store clips on a USB stick, so you can skip the subscription entirely. Check the current 4-pack price on Amazon.
Blink Outdoor 4 (single camera)
For a single-spot install — a back door, a side gate, or a detached garage — the single Blink Outdoor 4 is the budget pick. Same two-year battery, same 1080p sensor, same no-subscription option as the kit, but at a fraction of the price. The mounting bracket is small enough to fit on a 4x4 PVC block. See it on Amazon.
aosu T2 Pro Wireless Outdoor Security Camera (3K Dual Cam)
The aosu T2 Pro is the outlier here in the best way — it has two lenses in one body, so a single mounting block on vinyl siding covers both your driveway and your front walkway at the same time. 3K resolution is sharper than anything in Arlo's Essential line, and it stores locally on a microSD card with no monthly fee. The bracket is slightly bigger than the Blink mounts, so use a 4" x 6" PVC block rather than a 4" x 4". View the aosu T2 Pro on Amazon.
Blink Outdoor 2K+ Wireless Smart Security Camera
If image quality is the priority and you want to read license plates from the driveway, the new Blink Outdoor 2K+ is the upgrade pick. The bracket is identical to the Outdoor 4, so the same vinyl-siding install applies. See the 2K+ on Amazon.
Blink Outdoor 4 Wireless Security Camera System
This is the starter system — one camera plus the Sync Module 2 — and it's the cheapest way to start a no-subscription, local-storage camera network on vinyl siding. Add more cameras later; they all talk to the same Sync Module. Check the system kit on Amazon.
For more on choosing between these systems, see our guide to the best no-subscription outdoor cameras or our breakdown of outdoor cameras you can install without drilling.
Frequently Asked Questions
Can I mount Arlo Essential XL on vinyl siding without drilling at all?
Yes. Use a no-hole vinyl siding hook (Hillman, OOK, and Hyde all make them for about $4). It slides up under the bottom lip of a siding course and locks in place by gravity. The Arlo Essential XL's magnetic mount can attach to a small PVC scrap that hangs on the hook. Zero penetrations, zero leak risk, and you can take it down in 30 seconds.
What sealant should I use on vinyl siding camera mounts?
Use polyurethane sealant — NP1, Vulkem 116, or Loctite PL Premium are the standard choices. Avoid silicone: it doesn't bond to Tyvek or OSB, and nothing (including paint) sticks to it later. Butyl tape is even better as the primary waterproofing layer because it stays flexible for decades and compresses against the house wrap to form a gasket.
Will mounting an Arlo camera void my siding warranty?
It can. Most major vinyl siding manufacturers (CertainTeed, Mastic, Royal Building Products) specifically warn against face-drilling. Using a PVC mounting block keeps the install warranty-compliant because the block — not the siding — takes the fastener. Check your specific manufacturer's installation guide; almost all of them now list "exterior mounting block" as the approved method for any attached fixture in 2026.
How do I keep the Arlo Essential XL level on uneven siding?
The horizontal lips of vinyl siding aren't always perfectly straight, especially on older installs. A PVC mounting block solves this because it bridges multiple courses and gives you one flat reference surface. Shim behind the block with thin strips of cedar if the wall itself is out of plane. Then use a small torpedo level on the Arlo bracket before final tightening.
Can I run power through the vinyl siding to a wired Arlo Essential XL?
Yes, but route the cable through the mounting block, never through the siding directly. Drill a 1/2" hole through the block, then through the sheathing behind it. Run the cable, pack the hole with polyurethane sealant on both interior and exterior sides, and you have a permanent, weatherproof feed. This is the same method electricians use for exterior outlets and dryer vents.
What's the best alternative to the Arlo Essential XL for vinyl siding?
For most homeowners in 2026, the Blink Outdoor 4 is the closest competitor at a much lower price, with the bonus of two-year battery life and no required subscription. The aosu T2 Pro is the pick if you want dual-lens coverage from a single mounting point. Both install the same way — PVC mounting block, butyl tape, stainless screws.
How high should I mount the Arlo Essential XL on vinyl siding?
Eight to ten feet off the ground is the sweet spot. High enough that a casual passerby can't grab the camera, low enough that the field of view still captures faces (not just the tops of heads). For driveway-facing cameras, angle down about 15 degrees. The Arlo Essential XL's magnetic mount swivels freely, so you can fine-tune after installation without touching the screws. For a head-to-head spec comparison, see our Arlo vs. Blink outdoor camera comparison.
